Datasheet

The POE90U1BT Single Port PoE Injector from Pelco is designed to meet the data rate and power requirements of IP cameras with high-quality streaming video capabilities. It provides total power output of 90W, which meets the IEEE 802.3bt standard for detection, connection, disconnection, and fault protection. It is compatible with 10/100/1000Base-T systems. This injector supports AC input voltage of 100 to 240 VAC ± 10% and an input frequency of 47 to 63 Hz. The maximum output load current is 1.6A at 56 VDC.

Features :
.

  • Diagnostic LEDs
  • Broken wire detection
  • Overcurrent and overvoltage protection
  • The output can be shorted permanently without damage
  • Power cord required for operation (available separately)


General

Color
Black

Dimensions and weight

Width
80 mm
Depth
166 mm
Height
44 mm
Net weight
0.5 kg

Packaging info

Packaging size
219 x 152 x 65 mm
Packaging weight
757 g
Barcode
700880440346
