Professional A/V
- Pro view: Triple 50MP camera system with IntelliFocus
- Pro sound: 16-MEMS mic, 12m full-duplex voice without noise, stereo speakers
- Pro core: MTRA or MTRW
- For Android: Android 13 supported, MDEP
Streamline
- All in one: Meeting, display and whiteboard integrated, resulting in a 12-min setup and clutter-free spaces
- Movable: Get it rolling anywhere, anytime. Kick-off right away.
Optimized for Teamwork
- Whiteboard collaboration
- Wireless sharing
- Teams/Zoom/General Mode
- Extensibility(New): CM20, CS10
Triple 50 MP Camera System
- One wide-angle camera (middle), works within 3m and provides a wide field of view
- Two for telephoto(left & right), works beyond 3m Electric privacy shutter and optional 12 X Pro PTZ camera
On-device IntelliFocus
IntelliFocus displays close-ups of the last 4 active speakers separately, allowing more participants to appear on the screen and engage fully with the other party, thereby making the meeting more realistic.
- Smooth switching with fast and stable camera tracking.
- Enhance meeting concentration and maintain focus on the speakers.
- Providing a superior face-to-face conversation experience.
- Support IntelliFocus, auto framing, speaker tracking, Picture-in-Picture (PIP), Video fence
Pro Sound: To Hear, Be Heard
12m Full-Duplex Audio with 16 beamforming mic arrays, Noise Cancellation and Reverberation Suppression.
Support wire/wireless expansion mics: VCM35/VCM36-W/CM20/ CS10
MTRA or MTRW
The MeetingBoard Pro features dual-system, letting you choose between Windows and Android to suit your needs.
- MTRW - Higher security, Seamless management
- MTRA - Runs on latest Android 13, Enterprise-grade security with MDEP
MDEP Based, Meetings Secured
MeetingBoard Pro, based on Android 13, supports the Microsoft Device Ecosystem Platform (MDEP), ensuring a future-proof and secure meeting experience that effectively combats malicious attacks and data leaks.
Android-based platform from Microsoft
- Hardware-backed device attestation
- Secure monitoring service
- Enhanced management
- Secured deployment
Master devices in bulk with professional management platforms such as Microsoft Teams Admin Center (TAC), MTR Portal Management Platform(PMP), Zoom Device Platform (ZDM) and Yealink Management Cloud Service (YMCS).
Note! Floorstand and PTZ camera etc is not included. These are optional accessories. See "Acessories" Tab" for all optional accessories.
- Touch techology
- IR Touch
- Image diagonal
- 65 "
- Brightness
- 400 Nits
- Number of touchpoints
- 20 pcs.
- Mediaplayer
- Integrated Android Android 13 OS, Enterprise-grade security with MDEP, running on MT8195(13.2T) SoC
- VESA interface
- 600x400mm
- Haze value (%)
- 25
General
- Application/Certification
- Microsoft Teams Room, Zoom
- Platform/OS
- Android Android 13 with MDEP
- Room Size
- Large room 8p+
Camera
- Camera type
- Fixed Optic (EPTZ) Roomcamera Tripple Camera, 3x 50MP built-in cameras with IntelliFocus. External 12x optical zoom PTZ-camera (accessory)
- Resolution
- 3840x2160
- Framerate
- 30 FPS
- Optical zoom
- 0 x
- Digital zoom
- 4 x
- Field of view (horizontal)
- 98.2 °
- Programmable presets
- Yes 9x
- Auto framing/tracking
- Yes IntelliFocus, auto framing, speaker tracking, Picture-in-Picture (PIP), Video fence
Audio specifications
- Built-in microphone
- Yes 16x MEMS microphone array
- External microphone
- Yes Wired: VCM35, CM20, Wireless: VCM36-W
- Audio pickup range
- 12 m
- Built-in speaker
- Yes 4x Front facing stereo speakers
- External speaker
- Yes CS10
Communication
- Ethernet
- Yes x2, 10/100M/1000M Ethernet
- Wi-Fi
- Built-in Wi-Fi 6, 2.4G & 5G dual-band, 802.11a/b/g/n/ac/ax, 2x2 MIMO
- Content sharing
- Yes, via HDMI in, or optional VCH51 Sharing & BYOD Box (HDMI or USB-C interface). or USB-C in via optional CTP25 touch console.
- Wireless image sharing
- Yes, via AirPlay, Miracast or optional WPP30/PA20 wireless share pod/dongle (Max 4)
- Wired BYOD
- Yes, via optional VCH51 Sharing & BYOD Box (USB-C or HDMI & USB-A)
- Wireless BYOD
- Yes, via optional WPP30 wireless share pod/dongle (Max 4)
Connections
- Video in
- HDMI x1
- Video out
- HDMI x1 (supports CEC)
- Audio inputs
- Mic port (RJ-45) x2 Yealink VCH port
- Audio inputs
- RCA
- Audio outputs
- RCA
- USB connection
- USB-A x3
- USB connection
- USB-B x1 touch out interface
- USB standard
- 2.0
Energy
- Power Supply
- Power Adapter: AC 100~240V input
- Consumption Max
- 243 W
Dimensions and weight
- Width
- 1,484 mm
- Depth
- 105 mm
- Height
- 955 mm
- Net weight
- 40 kg
Additional information
- Color
- Silver
- Included Accessories
- Cable pack, AC power cable 3m, CAT5E network cable 3m, 4x Stylus pens, 3x Cable ties, Quick Start Guide
- Warranty
- 2 years
Packaging info
- Packaging size
- 1,660 x 220 x 1,050 mm
- Packaging weight
- 50.00 kg
