Datablad JBL SCS8 (pdf).pdf

The SCS 8 is comprised of a high-power coaxial 200 mm (8 in) low frequency driver and 25 mm (1 in) high frequency compression driver. The coaxial design utilizes a unique tapered pole-piece design and transitions to the cone of the low frequency driver as a large diameter pattern control horn for the high frequencies, both eliminating high-frequency beaming and extending pattern control to the lowest possible frequencies. The result is a coaxial speaker with wide, extremely consistent 120° broadband coverage.

Features

  • 250 Watt power handling (average continuous pink noise) with high sensitivity provides high SPL capability.
  • Consistent 120° x 120° broadband pattern control
  • Extraordinary clarity cinema surround with extended frequency response for special effects
  • Components:
    • 200 mm (8 in) woofer with Kevlar-reinforced cone and 50 mm (2 in)
    voice coil.
    • 25 mm (1 in) exit compression driver with unique patented design
    and high temperature polymer diaphragm.
  • 70 Hz – 20 kHz frequency response
  • High-power passive crossover network
  • Overload protection


General

Product series
Surround
Application
Surround
Active/Passive
Passive
Color
Black

Speaker drivers

LF
8 "

Packaging info

Packaging size
420 x 400 x 410 mm
Packaging weight
11.15 kg
