Plug and play connectivity
Simply unbox the GS1100 unmanaged switch, you can enjoy instant plug-n-play Gigabit connectivitywithout any additional settings required with auto-negotiation and auto MDI/MDI-X. Supporting 802.1pprioritization and jumbo frame, the switch ensures smooth voice and video traffic for your officenetwork.
Whisper quiet operation
The GS1100 Series has fanless design that ensures silent operation in small or quiet officeenvironments. The GS1100-10HP PoE model is specifically designed with an external power adapter thateliminates the need for an additional fan to cool down the device, making it perfect for quiet PoEdeployments.
Energy saving
The GS1100 features Energy Efficient Ethernet(IEEE 802.3az) which automatically detects networktraffic and adjusts power consumption dynamically. Zyxel’s green features also adjust powerconsumption by detecting the link status and cable length reducing business operating expenses.
Support PoE+
The GS1100-10HP supports PoE+ (IEEE 802.3at) which provides a maximum of 30W per port, deliveringfully automated support for powering compatible IP phones, video surveillance cameras or wirelessaccess points.
- Managed
- No
General
- Switch Class
- Unmanaged
- Form factor
- Desktop
- Switching capacity
- 20 Gbit/s
- Primary Port Speed
- 1 Gbit/s
- Primary Ports
- 8 x
- SFP Ports
- 2 x SFP+
Features
- PoE
- Yes 130W
- PoE Ports
- 8 x
- PoE Effect/Port
- 30 W
- PoE Budget
- 130 W
- Manageable
- Unmanaged
Dimensions and Weight
- Width
- 250 mm
- Depth
- 104 mm
- Height
- 27 mm
- Weight
- 0.73 kg
Additional Information
- Power consumption
- 156.1 W
- Warranty
- 5 years
Packaging info
- Packaging size
- 304 x 228 x 67 mm
- Packaging weight
- 1.72 kg
Packaging info (8 pcs)
- Packaging size
- 558 x 323 x 275 mm
- Packaging weight
- 13.70 kg
