Middle Atlantic C3 Display mounts convert your C3 Credenzas into full AV systems. We have partnered with Chief to create an industry leading display mount designed with height adjustment, cable management and minimal hardware for a quick and easy install.
- Compatible with the 24" High 1, 2, 3 & 4 Bay C3 Credenza frames and woodkits
- Telescoping uprights for display mount height adjustment
- 6” of post installation fine tune adjustment for perfect display placement
- Attaches to the wall using minimal hardware with the weight supported by the C3 Credenza and the stabilizing feet
- Supports dual displays with a 300lbs weight capacity
- Mounting pattern compatibility of 100x100 - 800x400
- Utilizing the Chief Fusion® extrusion, this display mount is compatible with applicable Fusion® series accessories including Camera Shelves supporting Vaddio cameras
- Includes white paintable upright covers to match wall color and blend the display mount into the environment
*To configure your C3 Credenza and retrieve the part codes needed, please use the C3 Credenza Configurator
- Height
- 1,333.5 mm
- Depth
- 73.7 mm
General
- Number of displays
- 2 pcs.
- Application
- Wall
- Color
- White Paintable
- Display orientation
- Landscape
- Videowall
- No
Functions
- Height adjustable
- Yes
- Side adjustment
- No
- Depth adjustment
- No
- Tiltable
- No
- Swing/Pan
- No
- Roll/Pivot
- No
- Motorized
- No
- Lockable
- No
Dimensions and weight
- VESA mount interface (mm)
- 100x100, 100x200, 200x100, 200x200, 200x400, 300x300, 300x400, 400x400, 500x400, 600x400, 700x400, 800x400
- Weight capacity (per screen)
- 68.04 kg
- Net weight
- 19.5 kg
Additional information
- Warranty
- 25 years
