C2G’s Superbooster 4-Port USB over Cat6a Extender Kit – USB 3.2 Gen 1 (5Gbps) was designed to extend data from USB 3.2, 2.0 and 1.1 devices simultaneously up to 328 feet (100m) over a single Cat6a F/FTP cable, making it a perfect solution for USB 3.2 conferencing cameras, interactive white boards, security and monitoring, remote storage, and/or any other USB 3, 2 and 1 device.
No software drivers are required, making installation quick and easy with true plug and play convenience. Simply connect the Transmitter to the source computer, extend with a single category cable, and connect the Receiver to as many as four USB devices.
This Superbooster 4-Port Extender Kit provides the ability to connect USB 3.2 Gen 1 (5Gbps) device types and is backwards compatible to USB 2.0 and 1.1 across a point-to-point connection.
Tested and Proven
This C2G Superbooster USB Extender has undergone rigorous compatibility testing with industry-leading video conferencing cameras, as well as solid state drives, docks, keyboards, mice and flash drives – ensuring total reliability and deployment confidence, plus saving valuable time for AV integrators as well.
General
- Extender type
- Transmitter & reciever kit
- Technology
- TP/CAT Cat6a
- Range (max)
- 100 m
Features
- USB standard
- 1.1, 2.0, 3.2 Gen 1
- Data transfer speed
- 5 Gbit/s
- USB power delivery
- 5V, 1,5A (7,5W)
- USB/Data connection from
- USB-B x1
- USB/Data connection to
- USB-A x4
Energy
- Power Supply
- DC 24V/ 2A with Bi-directional 24V PoC
Measurements and weight
- Width
- 100 mm
- Depth
- 85 mm
- Height
- 25,5 mm
Additional information
- Application
- Freestanding/Shelf
- Warranty
- 5 vuotta
Paketin tiedot
- Paketin mitat
- 255 x 149 x 81 mm
- Paketin paino
- 1,05 kg
