The BLU-102 contains dedicated AEC processing for up to 8 independent AEC algorithms. The AEC algorithm can be applied to signals coming from the local analog inputs or from the digital audio bus. 8 individual AEC references (one per algorithm) allow the user to provide a solution for multiple conferencing spaces using a single device.

12 Control Inputs and 6 Logic Outputs allow the BLU-102 to be integrated with GPIO compatible devices. The Soundweb London Interface Kit, comprehensive documentation which details how Soundweb London systems can be integrated with third party control systems, is included within the installation of HiQnet Audio Architect.

Features

  • 10 Analog Inputs (with 48v Phantom Power per Channel)
  • 8 Analog Outputs
  • RJ-11 Telephone Input/Output Port
  • Configurable Signal Processing
  • 8 Channels of AEC Processing with Auto Gain Control and Noise Cancellation
  • Rich Palette of Processing and Logic Objects
  • 48 Channel, Low Latency, Fault Tolerant Digital Audio Bus
  • Clear Front Panel LED Indication
  • Bi-Directional Locate Functionality
  • 12 Control Inputs and 6 Logic Outputs for GPIO Integration
  • Soundweb London Interface Kit for Third Party Control System Integration (Documentation)
  • HiQnet Device
  • Configuration, Control and Monitoring from HiQnet Audio Architect


Control
Ethernet/IP (RJ-45)
Control
GPI/O 12 Control Inputs / 6 Logic Outputs
Control
RS-232

General

Model series
BLU
Application
Fixed I/O

Connections

Ethernet
Kyllä
Audio inputs
BLU Link
Audio inputs
Euroblock line x10 (with 48v Phantom Power)
Audio outputs
BLU Link
Audio outputs
Euroblock line x8

Additional information

Application
19" Rack, 1U
Warranty
5 vuotta

Paketin tiedot

Paketin mitat
622 x 498 x 127 mm
Paketin paino
6,70 kg

Tarvikkeet

Artikkelinumero 2264074
Artikkelinumero 2264075
Artikkelinumero 2264078
