Hardware-controlled
microphone gain allows adjustment of microphone gain per channel. The 1261m device has a pre-configured architecture with input processing, a central matrix and output processing. Two input insert positions and one output insert position allow channel-specific insert processing to be configured. AutoWarmth®, a psychoacoustic function that maintains full frequency bandwidth even when the signal level has dropped, is permanently available on each output zone.
Features
- 12 Inputs / 6 Outputs
- 6 Balanced Mic/Line Inputs
- 4 Unbalanced, Mono-Summed RCA Input Pairs
- S/PDIF Input
- Microphone Gain per Channel
- Pre-Configured Architecture
- Two Configurable Input Insert Positions
- One Configurable Output Insert Position
- AutoWarmth® per Output Zone
- Link Bus
- Optional ZC Controllers
- Ethernet Control
- Serial Control
- Third Party Control
- Wizard-Driven Configuration
- Control
- Ethernet/IP (RJ-45), RS-232
General
- Model series
- ZonePro
- Application
- Fixed I/O
Connections
- Ethernet
- Kyllä
- Audio inputs
- Coaxial Digital S/PDIF
- Audio inputs
- Euroblock line x6 (Mic/Line)
- Audio inputs
- RCA x4 (Mono-Summed input pairs)
- Audio outputs
- Euroblock line x6
Additional information
- Application
- 19" Rack, 1U
- Warranty
- 2 vuotta
