Using the same technology and materials as the highly acclaimed Vela speaker line, the Vertex Series III combines the aesthetics of an architectural speaker with the performance and dynamics of the Vela series. The easily installed Vertex Series III speakers utilize the same components throughout the series to ensure a perfect sonic match across the line. Keeping with the philosophy of our famous Jet tweeter sound, Vertex series III speakers will complement any environment.
| Speaker type | 2 1/2-way, sealed cabinet |
|---|---|
| Tweeter | Jet Folded Ribbon |
| --- | --- |
| Woofers | 2 x 6” Active & 4 x 6” Passive Crystal Aluminum Sandwich Cones |
| --- | --- |
| Crossover frequency | 450 / 2,400 Hz |
| --- | --- |
| Frequency response | 38 to 50,000 Hz |
| --- | --- |
| Sensitivity | 88 db at 2.83 v/1m |
| --- | --- |
| Recommended amplifier power | 40 to 200 Watts |
| --- | --- |
| Nominal/peak power handling | 130/170 Watts |
| --- | --- |
| Nominal impedance | 4 Ohm |
| --- | --- |
| Finish | Black baffle/White grille |
| --- | --- |
| Grille | Metal magnetic / Paintable |
| --- | --- |
| Accessories included | Cutout template, manual |
| --- | --- |
| Dimensions | H: 46.61 in / 1184 mm W: 9.76 in / 248 mm |
| --- | --- |
| Cut-out | H: 45.75 in / 1162 mm W: 8.9 in / 226 mm |
| --- | --- |
| Mounting depth | 3.82 in / 97.0 mm |
| --- | --- |
