Kramer VM-2DH är en konverter som omvandlar en DisplayPort signal till HDMI och DVI.

  • Max. Data Rate - 4.95Gbps (1.65Gbps per graphic channel).
  • Resolution - Up to WUXGA a 1080p.
  • HDTV Compatible.
  • HDCP Compliant.
  • I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems.
  • Default EDID - For fast and efficient connection to the display.
  • Kramer Equalization & re-Klocking™ Technology - Rebuilds the digital signal to travel longer distances.
  • Standards Compliance - HDMI, HDCP, DDWG DVI 1.0.
  • Supports Up to 8 Embedded Audio Channels.
  • Compact DigiTOOLS® - 3 units can be rack mounted side−by−side in a 1U rack space with the optional RK-3T rack adapter.

**Applications: **
Multiple screen applications.
Rental and staging.



General

Application
Converter

Video specification

Resolution max out
1920x1200 4.95Gbps (1.65Gbps per graphic channel)
Refresh rate
60 Hz

Connections

Video inputs
1
Video outputs
1
Video in
DisplayPort
Video out
DVI-I Dual link
Video out
HDMI

Functions

Scaler
Ei
USB passthrough
Ei
Control
Front buttons

Energy

Power Supply
5V DC 800mA External Power Supply

Mitat ja Paino

Width
120 mm
Depth
71,5 mm
Height
24,4 mm
Net weight
0,2 kg

Additional information

Installation
19" Rack, 1U With RK-3T optional rack adapter
Installation
Freestanding/Shelf
Included Accessories
Power supply, mounting bracket
Warranty
7 vuotta

Paketin tiedot

Paketin mitat
155 x 120 x 85 mm
Paketin paino
607 g
