Datasheet

ASP6202-POE
Taking its audio from an external source such as a CCTV camera, the ASP6202-POE PoE Analogue Projector Speaker is ideal for applications such as Public Address in external environments.

Very loud, it is a great solution for helping to protect buildings, car parks, school playgrounds, solar farms and is a popular choice for mounting on mobile CCTV tower units.

Tech Specs
Model No
ASP6202-POE

Connectivity
1 No. RJ45 Plug
1 No. RCA Phono Plug (Line In)

Electrical
Effective frequency range, Hz (BSEN60268-5) 110-8,000
S.P.L. @ 1m, 1 watt, dB, Test Signal Bandwidth 100Hz-10 kHz 91
S.P.L. @ Full power Octave Bandwidth, dB 104
Acoustic Power (dB-PWL@1 watt) 1 kHz, dB 89/90
Dispersion at 1k/2kHz, Degrees 180/120
Directivity Axial Q factor, 1 k/2kHz 2.6/5.6

Power Supply
Power over Ethernet: IEEE802.3at or IEEE820.3af
Max Power Output: 25W (with IEEE802.3at supply)

Mechanical
Dimensions (Front & Depth): 138mm x 204mm
Net weight: 1.6kg
Colour/Finish: White
Material: ABS plastic housing with UV inhibitors
Mounting: Stainless Steel U Bracket

IP Rating: 56



General

Color
Valkoinen

Mitat ja Paino

Width
138 mm
Depth
204 mm
Net weight
1,6 kg

Lisäinformaatio

Warranty
2 vuotta

Paketin tiedot

Paketin mitat
190 x 185 x 285 mm
Paketin paino
1,58 kg
