General

CPU-Socket
Intel 1700
Chipset
B760
Form factor
ATX

Memory

Memory Type
DDR4
Channel Supported
Dual Channel
Memory frequency (base)
2 133 MHz
Memory slots
4 pcs.
Max Memory Supported
128 GB

Expansion Slots

PCIe generation
5.0
PCIe x16
2 pcs.
PCIe x1
2 pcs.

Storage Devices

M.2 slots
3 pcs.
M.2 support
2242/2260/2280/22110
M.2 generation
PCIe 4.0 x4
M.2 interface
PCIE 4.0 x4 and SATA modes
SATA ports
4 pcs.

Communications

LAN controller
Realtek
LAN Speed
2.5Gb Ethernet

Internal I/O Connectors

TPM
Kyllä
Thunderbolt
Kyllä
RGB
Kyllä
Fan Connector (4-pin)
5 pcs.

Rear Panel Ports

USB type-A
Kyllä
USB type-C
Kyllä
HDMI
Kyllä
DisplayPort
Kyllä
VGA
Kyllä
AUX out
Kyllä
Ethernet
Kyllä

Mitat ja Paino

Width
266 mm
Length
328 mm
Weight
1,16 kg

Paketin tiedot

Paketin mitat
336 x 271 x 60 mm
Paketin paino
1,15 kg

Paketin tiedot kpl

Paketin mitat
400 x 350 x 500 mm
Paketin paino
12,00 kg
