Ultraslim computer with 12th Gen Intel® Core™ processors, fan-less chassis for 15W CPU, 4K triple-display support, dual LAN, dual COM ports, PCIe® Gen 4 SSD, WiFi 6E, 50°C operational ambient temperature
Powered by Intel® 12th Generation processors
- Fan-less design for 15-watt CPU while minimizing noise and dust ingress
- 4K triple-display support via HDMI with EDID emulation and virtual display
- Slim and compact, measuring just 199.7 x 119.7 x 33.9 mm
- Comprehensive I/O ports including dual COM, dual LAN with 1x 2.5G and up to five USB ports
- Support up to up to 2x M.2 PCIe Gen4x4 SSD
- Integrated Wi-Fi 6E and Bluetooth for easy cordless connections
- Provide plenty of mounting solution including wall mount, din rail, VESA and rack mount
- Support up to 50°C operational ambient temperature 24/7 reliability — Extensively tested to ensure long-term dependability
Introducing ASUS PL Series Mini PCs
ASUS PL series mini PCs are designed mainly for indoor industrial applications. PL series mini PCs are subjected to strict testing standards, offer legacy connectivity and long product life cycles to cater to a diverse range of uses.
ASUS Mini PC PL64 employs a new fanless design that lowers operational noise and minimizes dust ingress into the chassis, prolonging product life. The fanless design and 15-watt CPU support make PL64 ideal for industrial applications where reliability, durability, and low noise are paramount.
Optimized Cooling Design
Designed to operate at up to 50° C ambient temperature. The cooling system of Mini PC PL64 is connected to a heatsink for efficient heat dissipation to ensure optimal performance even when deployed in hot environments reaching up to 50° C.
Compact Size with Metal Chassis
ASUS Mini PC PL64 measuring just 199.7 x 119.7 x 33.9 mm size and 0.81-liter chassis. The compact size makes PL64 suitable for digital signage, kiosk or any other space-constraint environments. Its metal chassis also makes PL64 more durable and perfect for industrial scenarios.
Advanced Output Management - EDID Emulation
Mini PC PL64 features Extended Display Identification Data (EDID) emulation and retains signage format so content being displayed remains unaffected even in the event of a temporary loss of power or connectivity issues, making it ideal for digital.
Virtual Display
PL64 can create virtual screens without a connected display. Virtual Display technology provides access to the system via a remote desktop, without affecting content that's currently being displayed, allowing an administrator to manage the system offsite.
- CPU Brand
- Intel
Suoritin
- CPU Model
- Core i5-1235U
- CPU Speed
- 4,4 GHz
- Number of cores
- 10 pcs.
- Number of threads
- 12 pcs.
Memory
- Memory
- 8 GB
- Memory Type
- DDR4
- Max Memory Supported
- 64 GB
- Memory slots
- 2 pcs.
Graphics
- Brand
- Intel
- GPU Model
- Intel® Iris® Xe Graphics
- Speed
- 1,2 GHz
Storage
- Device type
- PCIe 4.0 SSD
- Capacity
- 256 GB
Ports
- HDMI
- Kyllä
- USB type-A
- Kyllä
Communications
- Ethernet
- Kyllä
- WiFi Standard
- WiFi 6E (802.11axe)
- Bluetooth
- Kyllä
- Bluetooth standard
- 5.2
Mitat ja Paino
- Width
- 199,7 mm
- Depth
- 119,7 mm
- Height
- 33,8 mm
- Weight
- 1 kg
Additional information
- Material
- Metalli
- Color
- Musta
- Operating System
- Windows 11 Pro
- Power Supply
- 65 W
Paketin tiedot
- Paketin mitat
- 308 x 218 x 76 mm
- Paketin paino
- 2,09 kg
Paketin tiedot kpl
- Paketin mitat
- 350 x 300 x 400 mm
- Paketin paino
- 10,00 kg
